The EVO™ can communicate 200 yards through any obstruction. Depending on site conditions the distance could be longer.

Each EVO™ contains a pre-paired transmitter and receiver unit. The ratio of transmitters to receivers is always 1:1.

Yes, up to four (4) separate EVO’s can be installed in one location without interference between devices.

It’s dependent on the distance required and size of wire being installed, see chart below:

Yes, we recommend that the unit be installed to the bottom of the valve box lid as show in the Installation Manual. However if you choose to mount the Receiver somewhere else be sure to keep the same orientation as shown in the Installation Instructions. Make sure that the ‘Ribs’ are always facing up toward the sky and the LEDs are facing down toward the ground. Do not mount sideways.

No, the Transmitter and Receiver are paired by Thrive prior to shipping.

No, The LoRa radio can penetrate most site features including mature landscapes and some changes in elevation.

No, we encourage our customers to only actuate 4 stations per EVO™ with one valve per station wire.

DC latching solenoids only. These will be specific to the valve manufacturer in use.

No, The Thrive EVO is simply another path of communication between an irrigation controller and existing or new remote-control valves in the field – it’s just wireless.

Yes, Thrive offers a pancake antenna that replaces the standard antenna. Mount the pancake antenna on the outside of the metal pedestal to to achieve maximum transmission distance results.

Yes, the Transmitter can be located up to 100 feet away from an irrigation controller if necessary.

You may purchase a 120-volt to 24 VAC, step-down transformer from your local irrigation distributor and power the Transmitter with this device.

The product is shipped w/ Lithium batteries and are expected to last 1-1.5 years depending on usage.

Yes, but keep in mind that Alkali batteries are expected to have a much shorter service life.

No, this will void the product warranty. Always replace both batteries no matter the type used.

The EVO™ is compatible with the following two-wire controllers:

• Rainbird, ESP-2WIRE Series
• Rainbird, ESP-LXD Series 2-Wire Decoder Controller
• Hunter, ICC2
• Hunter, HPC
• Hunter, HCC
• Hunter, I-CORE®
• Hunter, DUAL® FOR I-CORE®
• Hunter, ACC 99D Two-Wire Controller
• Hunter, ACC2 Decoder Controller
• Hydropoint, WeatherTRAK Two-Wire PBT (OLD STLYE)

Known Incompatible 2-Wire Controllers are:

• Rainbird, ESP-LXIVM 2-Wire Controller with Smart Valve Technology
• ** Hydropoint, WeatherTRAK H20 (NEW STYLE)

**Compatible only if 1) Electrical alerts are turned off and 2) Two-wire Decoder 2 station module.

Please contact info@thrivesmartsystems.com if we can help assist in identifying other controllers’ compatibility.
